How Transitions Work

Transition as a Directed Graph

Statuses are nodes. Transitions are the directed edges between them. A record can only move along an explicitly defined edge — no implicit or free-form status changes.

draft ──submit──▶ pending ──approve──▶ active
                     │
                  reject
                     │
                     ▼
                 rejected ──reopen──▶ draft

This means:

• A pending record cannot jump directly to active unless pending → active is defined
• You can define multiple outgoing transitions from one status (branching)
• You can define transitions that go backwards (rollback paths)

What Happens During a Transition

1. User clicks the transition button in the UI
2. If a confirmation_message is set — confirmation dialog is shown
3. If a form is set — form drawer opens; user fills it in and submits
4. <name>_condition() is called — if it returns False, the transition is blocked
5. The record's status is updated to the to status
6. A WorkflowTransaction record is created (audit log)
7. <name>_done() is called — post-transition logic runs

Transition Types

Type	How triggered	form key	is_manual
Simple	User clicks button, confirms	Not set	True (default)
Form-based	User fills in a form drawer	Set to a form class	True (default)
System	Code only — not shown in UI	Optional	False

Audit Trail

Every transition automatically creates a WorkflowTransaction record containing:

• Which object transitioned
• Which transition was executed
• Who triggered it (request.user)
• Timestamp
• Any form data captured

This gives you a complete history of every status change for every record.

Transition Visibility in the UI

The frontend (WorkflowStatus component) shows only transitions that:

1. Start from the record's current status (from matches current status)
2. The current user's role is in roles (or roles is not set)
3. The _condition method returns True
4. is_manual is not False
